7.3 meter Super Large Permanent Magnet Brushless Internal Rotor Industrial Fan
Product Description
Logistics and Warehousing: Logistics warehouses, e-commerce operation warehouses, express delivery sorting centers.
Leisure and Tourism: Large amusement parks, parks, tourist attractions, characteristic towns, catering.
Sports: Cultural centers, stadiums, gyms, indoor training grounds.
Commercial Public Places: Large shopping malls, supermarkets, professional wholesale markets, exhibition centers, showrooms, car 4S shops.
Manufacturing: Industrial plants, production workshops.
Parameters
| Model |
Diameter |
Power Supply |
Max. Current (Amps) |
Power |
Max Speed |
Max Air Volume (m³/min) |
Noise Level (dB) |
Weight (KG) |
Area Covered (m²) |
Blades Qty |
Remarks |
| RDF-S3600 |
3600mm (12ft) |
Single 220V/50HZ |
2.6A |
0.66KW |
90 RPM |
4522 |
<38 |
72 |
20-24 |
5 |
Small Diameter |
| RDF-S4200 |
4200mm (14ft) |
Single 220V/50HZ |
2.6A |
0.66KW |
80 RPM |
5306 |
<38 |
75 |
22-26 |
5 |
Small Diameter |
| RDF-S5200 |
5200mm (17ft) |
Single 220V/50HZ |
2.6A |
0.66KW |
70 RPM |
7065 |
<39 |
78 |
25-30 |
5 |
Small Diameter |
| RDF-B6200 |
6200mm (20ft) |
Single 220V/50HZ |
4.5A |
1.3KW |
60 RPM |
10747 |
<39 |
100 |
32-37 |
5 |
Large Diameter |
| RDF-B6200 |
6200mm (20ft) |
Three 380V/50HZ |
3.1A |
1.3KW |
60 RPM |
10747 |
<39 |
100 |
32-37 |
5 |
Large Diameter |
| RDF-B6700 |
6700mm (22ft) |
Single 220V/50HZ |
4.5A |
1.3KW |
55 RPM |
12560 |
<39 |
105 |
35-40 |
5 |
Large Diameter |
| RDF-B6700 |
6700mm (22ft) |
Three 380V/50HZ |
3.1A |
1.3KW |
55 RPM |
12560 |
<39 |
105 |
35-40 |
5 |
Large Diameter |
| RDF-H7200 |
7200mm (24ft) |
Single 220V/50HZ |
4.5A |
1.3KW |
58 RPM |
15197 |
<39 |
115 |
38-44 |
5 |
High Air Volume |
| RDF-H7200 |
7200mm (24ft) |
Three 380V/50HZ |
3.1A |
1.3KW |
58 RPM |
15197 |
<39 |
115 |
38-44 |
5 |
High Air Volume |
Feature
1. Help reduce temperature by 3 degrees to 5 degrees
2. Can cover an area up to 22, 000 square feet.
3. Costs just pennies to operate.
4. Lowers summer energy consumption by at least 20%
5. Reduces winter energy consumption by up to 30%
6. Can replace up to 20 floor fans or smaller ceiling fans
7. Keep fresh air circulating to reduce bacteria, smoke, and mildew. Prevent damage caused by excessive moisture by helping keep these areas dry.
8. A cool and comfortable work environment allows your employees to perform at their best and deliver more effectively on company goals.
Advantages
Exceptional Airflow: Provides high-volume airflow, effectively cooling large areas and improving ventilation in industrial and commercial settings.
360-Degree Rotation: Allows for complete directional airflow, ensuring even distribution of air throughout the space and enhancing comfort.
Durable and Sturdy: Constructed with high-quality materials designed to withstand harsh environments, ensuring long-term reliability and performance.
Adjustable Height: The pedestal design enables height adjustments, allowing for targeted airflow at various levels and adaptability to different spaces.
Energy Efficiency: Engineered to deliver powerful airflow while consuming less energy, reducing overall operational costs.
Portability: Lightweight and equipped with wheels, making it easy to move the fan to different locations as needed.
Low Maintenance: Designed for easy cleaning and maintenance, minimizing downtime and ensuring consistent performance.
Versatile Use: Suitable for a variety of applications, including warehouses, factories, workshops, and outdoor events.
